Ethernet Interfaced:
10/100/1000BaseT, Compatible with Cambium PoE pinouts (V+ = 7 & 8, Return = 4 & 5) and Standard PoE pinouts (V+ = 4 & 5, Return = 7 & 8)
MAC (Media Access Control) Layer:
Cambium Proprietary
Network Management:
IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks cnMaestro
Physical Layer:
2x2 MIMO OFDM
Protocols Used:
IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
VLAN:
802.1Q with 802.1p priority
Modulation Levels (Adaptive):
MCS0 (BPSK) to MCS15 (64QAM 5/6)
Nominal Receive Sensitivity (w/FEC) @200MHz Channel:
MCS0 = -93 dBm to MCS15 = -72 dBm (per branch)
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel:
MCS0 = -90 dBm to MCS15 = -69 dBm (per branch)
Quality of Service:
Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority
Antenna Connection:
Integrated Antenna
Dimensions (HxWxD):
12.4 x 25.1 x 11.9 cm (4.9 x 9.9 x 4.7 in) – with mounting bracket attached
Input Voltage:
10 to 30 V
Pole Diameter Range:
1 – 1.6 in (2.5 – 4.1 cm) with included clamp ; up to 2.25 in (5.7 cm) with larger clamp
Surge Suppression:
2 Joule Integrated
Temperature:
-30°C to +60°C (-22°F to +140°F)
Wind Survival:
145 km/hour (90 mi/hour) with antenna
Weight:
0.50 kg (1.1 lb.) (includes mounting bracket)
Power Consumption:
10 W Maximum, 5 W Typical
