Ethernet Interfaced:
10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts
MAC (Media Access Control) Layer:
Cambium Proprietary
Network Management:
IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks cnMaestro
Proprietary Physical Layer:
2x2 MIMO/OFDM
Protocols Used:
IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
VLAN:
802.1Q with 802.1p priority
Modulation Levels (Adaptive):
MCS0 (BPSK) to MCS15 (64QAM 5/6)
Nominal Receive Sensitivity (w/FEC) @20 MHz Channel:
MCS0 = -92 dBm to MCS15 = -68 dBm (per branch)
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel:
MCS0 = -89 dBm to MCS15 = -65 dBm (per branch)
Quality of Service:
Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority
Transmit Power Range:
-15 to +30 dBm (combined, to regional EIRP limit) (1 dB interval)
Dimensions (Dia x Depth):
47 cm x 28 cm (18.5 in x 11.2 in)
Input Voltage:
10 to 30 V
Pole Diameter Range:
6.4 cm - 7.6 cm (2.5 in - 3 in)
Surge Suppression:
1 Joule Integrated
Temperature:
-30°C to +60°C (-22°F to +140°F) – with radome attached maximum temperature is +47°C (+116°F)
Wind Survival:
145 km/hour (90 mi/hour)
Weight:
5 GHz Model: 2.3 kg (5.1 lbs)
Power Consumption:
10 W Maximum, 5 W Typical
