Lightning Protection Unit

Lightning strikes are the most typical cause of system outages or failures of mast-mounted equipment, especially when mounted as high as 300m.

The Cambium Networks Lightning Protection Unit designed for the PTP 650 Series are ruggedized to operate in the toughest environments.

Описание

Lightning strikes are the most typical cause of system outages or failures of mast-mounted equipment, especially when mounted as high as 300m.

The Cambium Networks Lightning Protection Unit designed for the PTP 650 Series are ruggedized to operate in the toughest environments.

Спецификации

Connectors:
RJ 45
Dimensions (Including Glands):
6.3” Length (16 cm), 4” (10 cm) Width, 3.5” (9 cm) Height
Environmental Rating:
IP66/ IP67 (Dust and Water Intrusion Protection)
Humidity:
100% condensing
Mounting:
Pole mount 1-3” (25-75 mm) or wall mount
Operating Temperature:
-40° F (-40° C) to +140° F (+60° C)
Protection Mode:
Line-to-line and line-to-ground
Response Time:
5 nanoseconds typical
Surge Rating:
10/1000us 150 Amps min, 8/20us 1500 Amps min
Transfer Rate:
1000 Base T
Weight:
1.5 lbs (700 g)
Wing Loading:
150 mph (242 kph)
